RE-104 Conventional Fire Alarm Panel

RAVEL 2 Cone RE-104 Conventional Type Fire Alarm Control Panel.

The RE-104- is a two zone fire alarm control panel build with microprocessor. This panel can support inputs for 2 wire smoke detectors, manual call points and other normally open contact devices. The outputs are Notification Appliance Circuit i.e. Siren and hooters. Ravel Panel has options to connect-Three Form-C relays 2 for fire alarm, 1 fault and can be connected RS 485 Port to interface with remote annunciator(Optional) RE-102 Conventional Fire Panel Can Supervise supply of all wiring, AC Voltage and Battery Level.

Product Feature:

• Rugged CRCA sheet with powder coated finish.
• Operates on 220v, 50Hz AC supply.
• Standby battery back up with built in charging.
• Error free Fire / Fault status in unambiguous colored LED indication.
• Switch Mode Power Supply.
• 16 X 2 LCD Display.
• Tactile key pad for easy operation.
• Main, Standby status indication.
• Low Battery visual warning with audible tone.
• Zone wise one man walk test facility.
• Relay output for actuators.
• Lamp Test facility.
• Zone Isolation facility with loop voltage cut off.
• Programmable Keypad lock.
• Programmable Auto Silence.
• Compatible to all types of conventional detectors.
